Built this a few years ago. Have used it for a number of grows, I forget the GPM from each drip ring.
Upper and lower rez's
Upper rez with info
Red - Feed line to distribution manifold
Blue - Overflow from upper rez to lower rez
Green - Pressure regulation and recirculation
Yellow - pump from lower rez to refill upper rez and recirculation
Red arrow - anti siphon DIY device, pump running.
Distribution manifold 5 lines,one line to feed the drip ring on each pot.
Three point drip ring, no dripper's, just 3 inline T's. Feeding a 2 gallon smart pot.

This is from the current grow, its a three feed point drip ring, 9 T's feeding a 10 gallon smart pot. Pic shows it watering.
